4.22
ELECTRONIC FUEL INJECTION
Fuel Tank / Fuel Pump Replacement
IMPORTANT: Syphon as much fuel from the tank as
possible before attempting to remove it from the
vehicle.
1. Remove the driver and passenger seats along with the rear
service panel.
2. Disconnect the negative battery cable from the battery
located under the driver’s seat.
3. While holding a shop towel over the fuel line connector,
disconnect the quick connect fuel line from the fuel pump.
NOTE: A small amount of fuel may come out of the
fuel line or tank. Properly drain fuel into a suitable
container.
4. Disconnect the fuel pump electrical harness.
5. Remove the fuel tank vent hose.
6. Remove the (2) push rivets from the rear of the center
console.
7. Remove the (2) fasteners from the rear seat base and
remove the assembly from the vehicle.
WARNING
Always wear safety goggles when working with
high pressure or flammable fluids. Failure to do so
could result in serious injury or complications.
Disconnect Here
To Next Page
