ABCDE F G H
1
3
2
4
ABCDE F G H
1
3
2
4
ABC D E F GH JK L M
1
3
2
4
ECU 300 (Black)
ECU 100 (Grey)
Camshaft
Sensor
1
2
3
C3 5--Volt Supply
F3 Camshaft Signal
A2
Ground Reference
Splice 5
FUEL INJECTION / IGNITION / EXHAUST SYSTEMS
5.24
2004 Four Stroke PWC Service Manual
Camshaft Position Circuit
Circuit Trouble Codes
P -- Code Description Summary
P0340 Camshaft Sensor Circuit: Plausibility Error The camshaft sensor signal level is outside an acceptable range.
P0341 Camshaft Sensor Circuit: Signal Error Indicates a problem with the camshaft sensor signal switch from
high to low.
P0342 Camshaft Sensor Circuit: Short to Ground The camshaft sensor signal is shorted to ground.
P0343 Camshaft Sensor Circuit: Open or Short to Bat-
tery
The camshaft sensor signal is shorted to open or battery voltage.
