6
9926816 R07 - 2014-2016 RZR XP 1000 / XP4 1000 Service Manual
© Copyright Polaris Industries Inc.
6.31
REF. DESCRIPTION REF. DESCRIPTION
1
Fill Plug
44
Gear, Sector 16T
2
Drain Plug, Magnetic
45
Gear, Sector 31T
3
Screw, M8 x 1.25 x 30
46
Pawl, Detent
4
Screw, M6 x 1 x 20
47
Star, Detent
5
Screw, M8 x 50
48
Plate, Park, 12-Face
6
Screw, M6 x 1 x 40
49
Shaft, Output 53T
7
Screw, M6 x 1 x 18
50
Shaft, Idler 29T
8
Nut, NyLoc, M8 x 1.25
51
Shaft, Reverse 29T
9
Washer, Cup
52
Shaft, Front Output
10 Washer 53
Shaft, Input Helical
11 Washer 54 Bellcrank
12 Washer 55
Collar, Shift
13
Pin, Dowel
56
Rail, Shift Shaft
14
Pin, Spring
57
Tube, Vent, 1/4 in.
15
Retaining Ring, External
58
Shift Dog, Park
16
Snap Ring
59
Gear, 44T
17
Retaining Ring, External
60
Fork, Shift
18
Retaining Ring, External
61
Sprocket, 48T, 6-Face
19
Retaining Ring, Internal
62
Gear, Low 67T
20
Retaining Ring, External
63
Engagement Dog, 6-Face
21
Retaining Ring, External
64
Gear, 53T
22
Retaining Ring, External
65
Shaft, Pinion 11T
23
Retaining Ring, External
66
Gear, 46T
24
Washer, Thrust
67
Gear, Snorkel 13T
25
Washer, Thrust
68
Shaft, Shift
26 Shim 69
Weldment, Rear Mount Bracket
27 Shim 70
Bracket, Rear Mount
28
Bearing, Needle Cage
71
Cover, Bearing, Center Drive
29
Bearing, Ball
72
Spacer
30
Bearing, Ball
73
Chain, Silent
31
Bearing, Ball
74
Switch, Rotary, 2-Pin
32
Bearing, Ball
75
O-Ring
33
Bearing, Needle Cage
76
O-Ring
34
Bearing, Ball
77
O-Ring
35
Bearing, Ball
78
Seal, Triple Lip
36
Spring, Compression
79
Seal, Dual Lip
37
Spring, Compression
80
Seal, Triple Lip
38
Spring, Compression, Detent
81 N/A
39
Tube, Snorkel
82
Sensor, Speed
40
Cover, Sector Gears
85
Bearing, Ball
41
Case, RH
86
Spring, Wave
42
Case, LH
88
Bracket, Wire Harness
43
Drum, Shift
89
Collar Sleeve, Input Shaft
TRANSMISSION
