11. Reinstall the steering shaft assembly in the vehicle.

Install the lower portion of the steering shaft onto the

steering gear box assembly (see Figure 5-16).

Torque the lower pinch bolt to specification.

TORQUE

Lower Steering Pinch Bolt:

42 ft-lb (57 Nm)

12. Install the two fasteners that retain the pivot tube

(see Figure 5-17). Torque fasteners to specification.

TORQUE

Pivot Tube Bolts:

8 ft-lb (11 Nm)

13. Install the fastener retaining the upper portion of the

steering wheel tilt shock to the pivot tube (see Figure

5-17). Torque fastener to specification.

TORQUE

Tilt Shock Bolt:

7 ft-lb (10 Nm)

14. Be sure the front wheels are facing straight forward.

Remove the steering wheel and align as needed.

Torque the steering wheel nut to specification. Apply

Loctite

271

™

TORQUE

Steering Wheel Nut:

65 ft-lbs (88 Nm)

15. Wipe the pivot tube clean of any excess Loctite

16. Install steering wheel cap and field test steering

operation.
