8
9926816 R07 - 2014-2016 RZR XP 1000 / XP4 1000 Service Manual
© Copyright Polaris Industries Inc.
8.39
37. Check shock for any leaks.
NOTE
If leakage from a remote shock reservoir hose fitting is
evident, check for a loose fitting and seal threads with
Three Bond 1215 (PN 2871557)
38. Reinstall the compression spring and the spring
retainer.
39. Thread the spring preload adjuster down against the
spring and set the preload to the specified
measurement (see Chapter 2 – Spring Adjustment
(WALKER EVANS™), page ).
40. Set the compression adjuster knob to the
recommended setting or the original setting upon
removal (see Chapter 2 – Shock Compression
Adjustment (WALKER EVANS™), page 2.34).
41. Remove the shock from the vise.
42. Reinstall spherical bearing O-rings and polyurethane
bushings.
NOTE
After installation, be sure to RIDE SLOWLY initially to
ensure the shock and the vehicle’s suspension is
performing correctly.
STEERING / SUSPENSION
