Page 143
Common Parameters
P217, P227, P 237 - Relay Closures
The Ultra 3 will record how many times each relay is operated, this
parameter displays the number of times the relay has activated since the
relay has been in use. It can be reset with any value.
P218, P228, P238 - Relay Fail Safe
Your Ultra 3 has a general fail-safe parameter P808. However, this can be
overridden so that each individual relay has its own independent fail safe
mode.
This parameter determines what the relay will do in the event of the Failsafe
Time (P809) expiring.
Relay assumes system default mode P808
Relay remains in its current state
Data Log Parameters
The data log parameters contain the following information.
Totaliser Audits
When Ultra Wizard = 3 Flow
P460 to P479 Total Audits
Parameters P460-P479show the date and flow total for the last ten days, the
first on the list are the most recent and last ones are the oldest. When all ten
total audits are full the oldest is pushed out and all totals increment through
to allow the new days total to be registered in the first day’s total audit
parameter allocation.
Important Information
In order to ensure the accuracy of Flow during a 24-hour period, ensure that
the Time P932 is set correctly. And if required, enable Daylight Saving for
the appropriate time difference P970 – P979.
