The Quick Setup Menu detailing the questions you will be asked, when setting up
your Flow 3, via the Quick Setup is shown below.
Quick Setup Menu
PMD Type
0 = Off (No Calculation)
1 = Exponential
2 = BS3680 Flumes
3 = BS3680 Weirs
4 = Not Available
5 = Special
6 = Universal
For Each Alarm
1 = Set to Relay 1
2 = Set to Relay 2
3 = Set to Relay 3
Exponential
1 = Supp. Rect.
2 = Trapezoid
3 = Venturi 4 =
Parshall
5 = Leopold L.
6 = V-Notch
7 = Other
8 = Contracted Rect.
BS3680 Flumes
1 = Rectangular
2 = Rect. + Hump
3 = U-Throat
4 = U-Throat + Hump
BS3680 Weirs
1 = Rectangular
2 = V-Notch 90
o
(Full 90
o
)
3 = V-Notch 53
o
8’ (Half 90
o
)
4 = V-Notch 28
o
4’ (Qtr 90
o
)
5 = Broad Crested
Special
1 = Palmer Bowlus
2 = H-Flume
3 = V-Notch Angle
Calculation
1 = Absolute
2 = Ratiometric
How Many Alarms
0 = No Alarms
1 = One Alarm
2 = Two Alarms
3 = Three Alarms
For Each Alarm
1 = High Alarm
2 = Low Alarm
3 = Hi Hi Alarm
4 = Lo Lo Alarm
5 = Loss of Echo
Quick Setup
Universal
1 = Linear flow
2 = Curved flow
