Page 37
Vantage 3
The Vantage 3 level controller provides pump control with a complete range
of pump “duties” being available.
The Vantage 3 can measure from zero to 49.2 feet from the face of the
transducer to the surface being monitored, dependent on the transducer used.
The Vantage 3 can show level, space or distance on the display.
The three user definable relays with individual setpoints can be programmed
to activate alarms, pump starters, or other control equipment.
The 4-20 mA output is fully programmable to provide an output relative to
level, space or distance.
Flow
If you require to set up a flow application, then press “3” followed by
“ENTER” the message “Loading ***” will be displayed and your Ultra 3
will be configured as a Flow 3. Confirmation that configuration has been
completed will be given by the unit type, software version and serial number
being displayed briefly on the LCD and the unit advancing to the relevant
“Quick Setup” menu.
For full details on how to programme the Flow 3, using the Quick Setup
Menu, please proceed to Chapter 7 Flow. For a full description of all
features and parameters please refer to Chapter 8 Parameter Listing and
Description.
Flow 3
The Flow 3 open channel flowmeter provides comprehensive flow
monitoring with data logging and control functions for a complete range of
flumes, weirs and channels. Flow calculations to the British Standard
BS3680 are available within the software together with calculations for a
wide variety of other primary elements. Also available within the unit is a
customised 32 point calibration routine which also permits the flow
measurement of non - standard flumes and weirs.
The Flow 3 can measure from 0.00 m to 49.2 feet from the transducer to the
surface being monitored, dependent on the transducer used. The Flow 3 can
show details of level, space, distance, head or flow on the display along
with a totaliser if desired. The three user-definable relays with individual
setpoints can be programmed to activate devices such as pumps, samplers,
remote totalisers or other control equipment.
The 4-20 mA output is fully programmable to provide an output relative to
level, space, distance, head or flow.
