Page 167
Allocation
P841 mA Allocation
By default, the mA output will be representative of the reading obtained, as
determined by the Mode P100. When P100 = 5 (Volume) the output can be
assigned to be representative of the level. This parameter is automatically set
to the correct default option when selecting the Mode P100 and under
normal circumstances will not require changing.
The options, dependant on the value entered for Mode P100, are as follows:
mA output relates to Xducer 1 levels.
When Ultra Wizard = 1 Level/Volume
mA output relates to the volume. P100 = 5.
Compensation Parameters
Offset
P851 Measurement Offset
The value of this parameter is added to the measured distance, in
Measurement Units (P104).
This Offset will be added to the level, as derived from the transducer, and
will affect everything including the reading on the display, the relay
setpoints and the mA output.
Temperature
P852 Temperature Source
This parameter determines the source of the temperature measurement. By
default, it is set to automatic (P852=1), which will automatically detect if a
temperature sensor is available from the transducer. If for any reason, no
temperature input is received, then the Fixed Temp value is used, as set by
P854.
The temperature source can be specifically set as follows:
Will automatically select transducer
temperature sensor, if available, or fixed
temperature (P854) if no temperature
sensor found.
Always uses temperature reading from
transducer.
Always uses fixed temperature (P854)
To Next Page
