Page 166
Limits
P836 mA Low Limit
This parameter sets the lowest value that the mA output will drop to, the
default is 0mA, but you can override this if the device you connect to cannot
for example accept less than 2mA, yet you want to use the 0-20mA range.
Default = 0.00mA
P837 mA High Limit
This parameter sets the highest value that the mA output will rise to, the
default is 20 mA, but you can override this if the device you connect to
cannot for example accept more than 18 mA, yet you want to use the 0-20
mA range. Default = 20.00mA
Trim
P838 mA Low Trim
If the remote device you are connected to is not calibrated, and not showing
the correct low value (reading), then you can trim it using this parameter.
You can either type in the offset directly, or use the arrow keys to move the
output up and down until you get the expected result (reading) on the remote
device that the mA output is connected to.
P839 mA High Trim
If the remote device you are connected to is not calibrated, and not showing
the correct high value (reading), then you can trim it using this parameter.
You can either type in the offset directly, or use the arrow keys to move the
output up and down until you get the expected result (reading) on the remote
device that the mA output is connected to.
Failsafe
P840 mA Fail-safe Mode
This parameter determines what happens to the mA output in the event of
the unit going into fail-safe mode. The default is to do the same as the
system fail-safe (P808), but this can be overridden to force the mA output
to an independent fail-safe mode as follows:
