4 – Managing Switches
Configuring a Switch
4-22 59226-00 B
S
4.7.3
Advanced Switch Properties
The Advanced Switch Properties dialog enables you to set timeout values, Interop
Mode, and Legacy Address Format settings. The Advanced Switch Properties
dialog is available for only the entry switch, because an in-band switch can not be
taken offline. The switch will automatically be taken offline temporarily and will be
restored to its original state after the changes are completed. To open the
Advanced Switch Properties dialog, open the Switch menu and select Advanced
Switch Properties. After making changes, click the OK button to put the new
values into effect.
Use the Advanced Switch Properties dialog, show in Figure 4-10, to change the
following switch configuration parameters:
Timeout Values
Interop Mode for Zoning
Legacy Port Address Format
Figure 4-10. Advanced Switch Properties Dialog
