5 – Managing Ports
Port Statistics Data Window
59235-02 A 5-5
L
5.2
Port Statistics Data Window
The Port Statistics data window, shown in Figure 5-3, displays statistics about port
performance. To open the Port Statistics data window, select one or more ports
and click the Port Stats data window tab.
Figure 5-3. Port Statistics Data Window
Media Vendor The company that manufactured the SFP
Media Vendor ID The IEEE registered company ID
Media Part Number The part number assigned to the SFP
Media Revision Transceiver hardware version
Table 5-1. Port Information Data Window Entries (Continued)
Entry Description
To Next Page
