QTech QSW-4700 Series User Manual

QSW-4700 Series Switches Hardware Installation and Reference Guide
Product Overview
15
Model
QSW-4700-52TX
Fan
Fan Speed Control
Fan Fault Alarming
Temperature
Alarming
Supported
EMI
Certification
GB9254-2008CLASS A
Safety
Regulation
Compliance
GB4943-2011
Dimensions
(W x D x H)
442 mm x 420 mm x 43.6 mm (17.40 in. x 16.54 in. x 1.72 in.)
Weight
4.3 kg (9.48 lbs.)
1.3.2. Appearance
The front panel of the QSW-4700-52TX Ethernet switch provides 48 10/100/1000Base-T
Ethernet ports, four 10GE SFP+ ports, one management port, one Console port and one USB
port. The back panel has two power supply module slots.
Figure 1-5 QSW-4700-52TX Switch Appearance
1.3.2.1. Front Panel
Figure 1-6 Front Panel of QSW-4700-52TX
1. System Status LED
2. Management Port LED
