QTech QSW-4700 Series User Manual

QSW-4700 Series Switches Hardware Installation and Reference Guide
Product Overview
40
Function
Panel ID
Color
Status
10GE SFP+ Port
LED
49F to
52F
Off
No link is detected for this port.
Solid Green
The port has made a successful
1/10 Gbps link.
Blinking Green
The port is sending and receiving
traffic at 1/10 Gbps.
GE SFP Port
LED
1F to 48F
Off
No link is detected for this port.
Solid Green
The port has made a successful
100/1000 Mbps link.
Blinking Green
The port is sending and receiving
traffic at 100/1000 Mbps.
1.8. Power Supply Module
1.8.1. QSW-M-4700-AC Module
The QSW-4700-28TX, QSW-4700-52TX, QSW-4700-28F and QSW-4700-52F switches support
the QSW-M-4700-AC power module. The QSW-M-4700-AC is an AC module (AC/HVDC input
and DC output) providing an output voltage of 12 V and an output power of up to 150 W.
Note:
• The switch can be powered on by either one power supply module or dual power supply
modules. If both power supply modules are used, the switch works in the power
redundancy mode.
• At least one power supply module is required. If any slot is unoccupied, install a filler
panel to enable proper airflow.
1.8.1.1. Specifications
Item
Specification
Power Supply
Model
QSW-M-4700-AC
Switch Model
QSW-4700-52F
Rated Input
Voltage Range
AC Input: 100 V AC to 240 V AC, 50 Hz/60 Hz
HVDC Input: 240 V DC
Maximum Input
Voltage Range
AC Input: 90 V AC to 264 V AC, 47 Hz/63 Hz
HVDC Input: 192 V DC to 288 V DC
Maximum Input
Current
3 A
Output Voltage
12 V
