Product Overview
48
input and DC output) providing an output voltage of 56 V and an output power of up to 1000 W
(PoE power: 740 W).
Note:
• The switch can be powered on by either one power supply module or dual power supply
modules. If both power supply modules are used, the switch works in the power
redundancy mode. The switch supports 1+1 power redundancy when the PoE power
consumption is less than 740 W.
• At least one power supply module is required. If any slot is unoccupied, install a filler
panel to enable proper airflow.
1.8.5.1. Specifications
Item
Specification
Power Supply
Model
QSW-M-4700-HPOE-AC
Switch Model
QSW-4700-28TX-POE, QSW-4700-52TX-POE
Rated Input
Voltage Range
AC Input: 100 V AC to 240 V AC, 50 Hz/60 Hz
HVDC Input: 240 V DC
Maximum Input
Voltage Range
AC Input: 90 V AC to 264 V AC, 47 Hz/63 Hz
HVDC Input: 192 VDC to 288 VDC
Maximum Input
Current
12 A (Input Voltage: 100 V AC)
8 A (Input Voltage: 200 V AC)
Output Voltage
56 V
Maximum Output
Current
17.86 A (Input Voltage: 176 V AC to 290 V AC or 190 V DC to 290
V DC)
16.61 A (Input Voltage: 90 V AC to 176 V AC, 176 V AC not
included)
Maximum Output
Power
1000 W (Input Voltage: 176 V AC to 290 V AC or 190 V DC to 290
V DC)
930 W (Input Voltage: 90 V AC to 176 V AC, 176 V AC not
included)
PoE Power
Consumption
740 W (Dual power supply modules: 1480 W)
Ground Leakage
Current
≤ 3.5 mA
Dimensions (W x
D x H)
196 mm x 90 mm x 40 mm (7.72 in. x 3.54 in. x 1.57 in.)
Weight
1 kg (2.20 lbs.)
Operating
Temperature
-10°C to 55°C (14°F to 131°F)
