QTech QSW-4700 Series User Manual

QSW-4700 Series Switches Hardware Installation and Reference Guide
Product Overview
30
Function
Panel ID
Color
Status
10/100/1000Base-T
Ethernet Port LED
1F to 48F
Off
No link is detected for this port.
Solid
Green
The port has made a successful
10/100/1000 Mbps link.
Blinking
Green
The port is sending and receiving
traffic at 10/100/1000 Mbps.
PoE Status LED
1F to 48F
Off
PoE is disabled.
Solid
Green
PoE is enabled.
Blinking
Green
(3 Hz)
PoE overload occurs.
1.5.6. LED Mode Button
The LED Mode button is used to switch the LED mode. The green LED Mode indicator indicates
the switching status. Press the LED Mode button, and the LED Mode indicator will turn yellow,
indicating the PoE status. Press the LED Mode button again, the indicator switches to indicating
the switching status.
If you want to switch the LED mode, press the button for over two seconds.
1.6. QSW-4700-28F
1.6.1. Specifications
Model
QSW-4700-28F
CPU
Dual-core CPU with the clock speed of 1.2 GHz
BOOTROM
16 MB
Flash Memory
2 GB
SDRAM
1 GB
SFP Module
Type
• SFP Port:
• SFP Modules and SFP BIDI Modules
• SFP+ Port:
• SFP Modules and SFP BIDI Modules
• SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules.
• See Chapter 7 for details.
Note:
• The module types may update without prior notification.
Please contact Qtech for details.
