LPWA Module Series
BG95 Hardware Design
BG95_Hardware_Design 19 / 80
1. eSIM function is optional. If eSIM is selected, then the external (U)SIM cannot be used
simultaneously.
2. RESET_N will be supported in the next hardware design version.
3. ADC0 and ADC1 cannot be used simultaneously. BG95 supports using of only one ADC interface at a
time: either ADC0 or ADC1. Currently only ADC0 is enabled, and ADC1 will be enabled in the next
hardware design version.
4. “*” means under development.
2.4. Evaluation Board
In order to help customers to develop applications conveniently with BG95, Quectel supplies the
evaluation board (EVB), USB to RS-232 converter cable, USB data cable, earphone, antenna and other
peripherals to control or test the module. For more details, please refer to document [1].
NOTES
