Quectel BG95 Series User Manual

LPWA Module Series
BG95 Hardware Design
BG95_Hardware_Design 66 / 80
Table 35: BG95 RF Output Power
1.
1)
LTE-FDD B14 and B27 are supported by Cat M1 only.
2.
2)
LTE-FDD B71 is supported by Cat NB2 only.
3. “*” means under development.
6.5. RF Receiving Sensitivity
The following table shows the conducted RF receiving sensitivity of BG95.
Table 36: BG95 Conducted RF Receiving Sensitivity
Frequency Max. Min.
LTE-FDD B1/B2/B3/B4/B5/B8/B12/B13/B14
1)
/B18/B19/B20/B25/
B26*/B27
1)
/B28/B66/B71
2)
/B85
20dBm±2dB <-39dBm
GSM850/EGSM900 33dBm±2dB 5dBm±5dB
DCS1800/PCS1900 30dBm±2dB 0dBm±5dB
GSM850/EGSM900 (8-PSK) 27dBm±3dB 5dBm±5dB
DCS1800/PCS1900 (8-PSK) 26dBm±3dB 0dBm±5dB
Network Band Primary Diversity
Sensitivity (dBm)
Cat M1/3GPP Cat NB2
1)
/3GPP
LTE
LTE-FDD B1
Supported
Not
Supported
TBD/-102.7 TBD/-107.5
LTE-FDD B2 TBD /-100.3 TBD/-107.5
LTE-FDD B3 TBD /-99.3 TBD/-107.5
LTE-FDD B4 TBD /-102.3 TBD/-107.5
LTE-FDD B5 TBD /-100.8 TBD/-107.5
LTE-FDD B8 TBD /-99.8 TBD/-107.5
LTE-FDD B12 TBD /-99.3 TBD/-107.5
