Quectel BG95 Series User Manual

LPWA Module Series
BG95 Hardware Design
BG95_Hardware_Design 20 / 80
3 Application Interfaces
BG95 is equipped with 102 LGA pads that can be connected to customers’ cellular application platforms.
The following sub-chapters will provide detailed description of interfaces listed below:
 Power supply
 (U)SIM interface
 USB interface
 UART interfaces
 PCM* and I2C* interfaces
 Status indication
 USB_BOOT interface
 ADC interfaces
 GPIO interfaces
“*” means under development.
