Quectel LPWA Series User Manual

LPWA Module Series
BG950A-GL&BG951A-GL_Hardware_Design
54
/ 84
5 RF Specifications
5.1. Cellular Network
5.1.1. Antenna Interface & Frequency Bands
The pin definition is shown as below:
Table 31: Pin Definition of Cellular Network Interface

Table 32: Operating Frequency of BG950A-GL & BG951A-GL
Pin Name
Pin No.
I/O
Description
Comment
ANT_MAIN
60
AIO
Main antenna interface
50 Ω impedance
Only passive antennas are supported.
Operating Frequency
Transmit (MHz)
Receive (MHz)
Unit
LTE HD-FDD B1
1920–1980
2110–2170
MHz
LTE HD-FDD B2
1850–1910
1930–1990
MHz
LTE HD-FDD B3
1710–1785
1805–1880
MHz
LTE HD-FDD B4
1710–1755
2110–2155
MHz
LTE HD-FDD B5
824–849
869–894
MHz
LTE HD-FDD B8
880–915
925–960
MHz
LTE HD-FDD B12
699–716
729–746
MHz
