Quectel LPWA Series User Manual

LPWA Module Series
BG950A-GL&BG951A-GL_Hardware_Design
55
/ 84
5.1.2. Tx Power
The following table shows the Tx power of the module.
Table 33: RF Output Power
9
LTE HD-FDD B17 is supported by Cat NB2* only.
10
LTE HD-FDD B26 and B27 are supported by Cat M1 only.
LTE HD-FDD B13
777–787
746–756
MHz
LTE HD-FDD B17
9
704–716
734–746
MHz
LTE HD-FDD B18
815–830
860–875
MHz
LTE HD-FDD B19
830–845
875–890
MHz
LTE HD-FDD B20
832–862
791–821
MHz
LTE HD-FDD B25
1850–1915
1930–1995
MHz
LTE HD-FDD B26
10
814–849
859–894
MHz
LTE HD-FDD B27
10
807–824
852–869
MHz
LTE HD-FDD B28
703–748
758–803
MHz
LTE HD-FDD B66
1710–1780
2110–2180
MHz
Frequency Bands
Max. Tx Power
Min. Tx Power
LTE HD-FDD:
B1/B2/B3/B4/B5/B8/B12/B13/B17
9
/B18/B19/
B20/B25/B26
10
/B27
10
/B28/B66
23 dBm ±2.7 dB
< -39 dBm
