- equivalents of navigating arrows
Moving the cursor up in the menu list
Exit to higher level in menu structure , e.g. to
main menu
Entering settings of a selected submenu.
Moving the cursor down in the menu list
- equivalents of ENTER / PRINT key and ESC key
Accepting entered value of a parameter
5.1.4. Moving in the user menu using virtual keyboard, via RS 232
interface
Most of the functions controlled or set using balance’s overlay or an external computer
keyboard PS/2 type can be carried out by a set of commands sent from a computer to a
balance.
The commands enable moving through user menu, setting parameters or controlling
balance operation. The list of commands is provided at the end of this user manual.
5.2. User menu - content
Menu structure of a balance AS/X series is described in point 5 of this user manual. On
order to enter software’s main menu, when in the main weighing window press Setup key.
The display opens a list with main menu. By pressing up and down navigating arrows
move the cursor and place it next to a submenu to be edited.
