RADWIN5000ConfigurationGuide Release4.9.17 5‐3
SUPRO/AIRWebInterface(viaPCorlaptop) SUPRO/AIRConfiguration
Figure5‐1:SUPRO/AIRMain/OverviewWindow
Thefollowingparametersalwaysappearinthetopsection:
Status: Indicatesifalignmentisrequired.
RSS: Radiosignalstrengthasreceivedbytheunit.
LANTx/Rx: ShowsLANspeedofunit(HSU)ineachdirection
UpTime: Totalamountoftimesincelastresetofunit
SectorID: TheidentificationnumberassetintheHBS
Seria
lNumber: Thenumberfortheunittowhichyouareconnected
SWVersion: Softwareversionoftheunit(HSU)towhichyouareconnected
HWVersion: Hardwareversionoftheunit(HSU)towhichyouareconnected
Thelinksontheleftofthewidowprovidethreemaincategories:
Overview
BringsyoubacktotheMainWindow
Configure
Allowsyoutoconfigurevariousparametersoftheunit
Tools
Providesbackupandupgradetools,aswellasnetworkanalysis
tools
