Radwin 5000 User Manual

RADWIN5000ConfigurationGuide Release4.9.17 5‐4
Overview SUPRO/AIRConfiguration
5.4Overview
Theitemshereareallread‐only.
System
ThefollowingparametersaredisplayedforboththeSUPRO/AIR(shownasHSU)anditsbase
station(shownasHBS):
• Unitname(asdefinedbytheuser)
• Unitlocation(nameoflocationasdefinedbytheuser)
• IPaddressoftheunit
• Subnetmask
DisplayedfortheSUPRO/AIR only:
• Defaultgateway
• MACaddress
Radio
Thefollowingparametersaredisplayed:
• Thelocationoftheunit(latitudeandlongitude)
• SectorID
• Frequencyused
• FrequencyBand
• ChannelBandwidth
DeviceMonitor
ThefollowingparametersaredisplayedseparatelyfortheSUPRO/AIRanditsHBS:
• IndicationsforRSSvalues
• Throughput
• LANspeeds(T xandRx)
Events
Thisareashowsalistofeventsregardingtheradiounit.
