RADWIN5000ConfigurationGuide Release4.9.17 7‐11
HSU MonitoringandDiagnostics
Databecomesinvalidatedfollowingareset.Intheexamplebelow,theHBSwasresetshortly
after11:00.Alldatapriortothattimebecomesinvalidated.Theonlyvaliditemisthefirst
recordingafterre‐sync.
Figure7‐9:HBS‐PerformanceMonitoringreport‐Showinginvaliddata
UsetheSavebuttontostorethecurrentdatatofileandtheClearbuttontodeletecurrently
storedperformancedata.
7.6.2HSU
ThePerformanceMonitoringwindowfortheHSUisslightlydifferentdependingonwhether
youaccessitfromtheHBSordirectly:
ES Erroredseconds
Thenumberofsecondsinwhichtherewasatleastone
errorblock.
SES
SevereErrored
Seconds
Thenumberofsecondsinwhichtheservicequalitywas
lowasdeterminedbytheBBERthreshold.
BBE
BackgroundBlock
Error
Thenumberoferroredblocksinaninterval.
RxMBytes ReceivedMbytes
ThenumberofMegabytesreceivedatthespe
cifiedport
withintheinterval
TxMBytes
Transmitted
Mbytes
ThenumberofMegabytestransmittedatthespecifiedport
withintheinterval.
AboveTraffic
Thresh
Thresholdsetin
Figure 7‐7
Secondscountwhenactualtrafficexceededthethreshold
ActiveSeconds
ThenumberofsecondsthattheconfiguredEthernet
serviceis active
Table7‐2:HBSPerformanceMonitoringFields(Continued)
ColumnHeading
Abbreviation
Meaning
Description
