RADWIN5000ConfigurationGuide Release4.9.17 9‐7
ManagingtheHBSovertheAirfromanHSU VLANFunctionality
• Separatethemanagementanddataports
• DefineonlyadataportwithProviderfunction
9.5.2ManagingtheHBSovertheAirfromanHSU
IftrafficVLANtaggingisinforcefortheHSUingressdirectionandmanagementVLANisinuse
attheHBS,thentheVLANIDattheHSUingressdirectionmustbethesameastheVLANID
formanagementattheHBS.
9.5.3ConfigurationofVLANTaggingforEthernetService
VLANconfigurationiscarriedoutperHSU.Itisuptoyoutoensureconsistencybetweenthe
HSUs.
HSUVLANtaggingcanonlybeconfiguredfromone of the HSU views from the HBS.Youcan
notlogontoanHSUdirectlyanddoitfromtheHSUmainwindow.ThereasonisthattheHBS
maintainstheHSUtagginginformationinitsinternalperHSUconfigurationrecord.
 TosetupanHSUforVLANtagging:
1. RightclickanHSUontheHBSwindow,andthenclickConfigure|Ethernet|VLAN
Configuration.TheVLANConfigurationwindowisdisplayed:
