RADWIN5000ConfigurationGuide Release4.9.17 7‐2
RetrievingLinkInformation(GetDiagnostics) MonitoringandDiagnostics
Thefollowingtablelistslinkandsysteminformationthatcanbemonitored.
 Togetdiagnostics:
1. ClicktheGetDiagnosticsbutton:
Figure7‐1:GetDiagnosticsDialogBox‐HBS
Table7‐1:GetDiagnosticsDat aandDescription
Data Description
SystemData Generalinformationaboutthesystem
EventsLog
•Listofsystemeventsincludingthosefromothersitesifthissiteis
definedasthetrapdestination
•Last256eventsfromallsites
SectorInformation InformationabouttheHBSandHSUsettings
SiteConfiguration Dataaboutthesiteparameters
Monitor Detailedeventdatarecord
RestrictionTable ThisistheConnectionTablefromFigure 4‐23
ActiveAlarms ActiveAlarmsareraisedforanyeventaffectingavailabilityorqualityof
Performance Networkperformancedataoverdefinedtimeperiods‐‐every15minutes
SpectrumAnalysis ForHBS
,selectedHSUsandgeneralinterfencestatisticsforthesector
