RADWIN5000ConfigurationGuide Release4.9.17 9‐5
PortFunctionality VLANFunctionality
IngressDirection
EgressDirection
Table9‐1:Portsettings‐Ingressdirection
Transparent Theport‘doesnothing’with regardtoVLANs‐inboundframesareleftuntouched.
Tag
FramesenteringtheHSUportwithoutVLANorQinQtaggingaretaggedwithVLAN
IDandPriority
a
,whicharepreconfiguredbytheuser.Frameswhichar ealready
taggedatingressarenotmodifiedandpassthrough.
a. Priority Code Point (PCP) which refers to the IEEE 802.1p priority. It indicates the frame priority level
from 0 (lowest) to 7 (highest), which can be used to prioritize different classes of traffic (voice, video,
data, etc).
Providertag
FramesenteringtheHSUportaretaggedwithprovider’sVLANID andPrioritywhich
arepreconfiguredbytheuser.Frame.swhicharealreadytaggedwithProvider
taggingattheingressarenotmodifiedandpassedthrough
.
Table9‐2:Portsettings‐Egressdirection
Transparent Theport‘doesnothing’withregardtoVLANs‐outboundframesareleftuntouched.
