IconDescription
Rear-viewmode—imageisippedhorizontally.
Zoomsetting:2xzoom.
Zoomsetting:4xzoom.
Singleactivecontrolleronnetwork.
Multipleactivecontrollersonnetwork.
PC/laptopdetectedonnetwork.
Pointmodeenabled.
Pointmodedisabled.
StabilizationOff.
StabilizationOn.
FFC(FlatFieldCorrection)
PeriodicallythecamerawillperformaFlatFieldCorrection
(FFC).Thiswillnetunethethermalimagetosuitthecurrent
ambienttemperature.
TheFFCoperationisindicatedbyamomentarypauseanda
greenrectangledisplayedintheupperleftofthethermalvideo
image.
19.3Controlsoverview
Thethermalcameraapplicationisavailableoncompatible
Raymarinemultifunctiondisplaysandsystems.Itincludes
controlsforthethermalcamera.
Rotarycontrol
Zoomimagein/out.
Joystick•Panandtiltcamera
Note:Ontouchscreendisplaysyou
canalsousethetouchscreentopan
andtiltthecamera.
•Navigatemenus
OKConrmmenuselection
CANCEL/BackCancelselection
RANGEIN/OUTZoomimagein/out.
Thermalcameraapplication—Panandtiltcameras
217
