Raymarine Ray260 User Manual

Extendedsystem
0
00
00
SeaTalk
ng
INTCM
INTCM
INTCM
1
6
3
9
5
2
7
10
D1281 1-1
4
8
1.Station1activespeaker
2.Station1handset
3.Ray260basestation
4.Loudhailer
5.GPSreceiver
6.Station2activespeaker
7.Station2handset
8.Station3handset
9.Station3passivespeaker
10.Multifunctiondisplay
Note:Eachstationcansupportconnectionof1passiveOR1activespeaker.
3.3Installationchecklist
Installationincludesthefollowingactivities:
InstallationTask
1Planyoursystem.
2
Obtainallrequiredequipmentandtools.
3
Siteallequipment.
4Routeallcables.
5
Drillcableandmountingholes.
6Makeallconnectionsintoequipment.
7
Secureallequipmentinplace.
8Poweronandtestthesystem.
3.4Schematicdiagram
Aschematicdiagramisanessentialpartofplanningany
installation.Itisalsousefulforanyfutureadditionsor
maintenanceofthesystem.Thediagramshouldinclude:
•Locationofallcomponents.
•Connectors,cabletypes,routesandlengths.
16
Ray260
