5.2
Base
station
dimensions
The
dimensions
of
the
Ray260
base
station
are
shown
below
.
C
D
1
2
6
0
6
-
1
A
B
D
A
269.5
mm
(10.6
in)
B
168
mm
(6.6
in)
C
66.12
mm
(2.6
in)
D
80.0
mm
(3.15
in)
Handset
dimensions
The
dimensions
of
the
handset
are
shown
below
.
0
0
0
INTCM
A
D
C
B
D12609-2
A
65.4
mm
(2.57
in)
B
154.4
mm
(6.07
in)
C
7
mm
(0.275
in)
D
38.5
mm
(1.5
in)
Speaker
dimensions
The
dimensions
of
the
Ray260
passive
/
active
speaker
are
shown
below
.
Note:
The
passive
speaker
does
not
have
a
volume
control
knob.
0
A
G
B
C
D
E
F
D
1
2
6
0
7
-
1
A
1
12
mm
(4.4
in)
B
1
12
mm
(4.4
in)
C
20.3
mm
(0.799
in)
D
15.55
mm
(0.61
in)
E
25
mm
(0.98
in)
F
30
mm
(1.18
in)
G
91.5
mm
(3.6
in)
Location
and
mounting
27
26
28
