Raymarine Ray260 User Manual

4.4NMEA0183connection
TheNMEA0183wiresonthepower/datacablecanbeusedto
connecttheradiotoaGPSreceiveroraRaymarinemultifunction
display.
Note:ConnectionscannotbemadeusingSeaT alk
ng
and
NMEA0183atthesametime.
D12 61 3-1
3
4
5
6
1
2
1.Ray260basestation.
2.Power/datacable.
3.Yellow–Receivepositive(+)wire.
4.Green–Receivenegative(-)wire.
5.White–Transmitpositive(+)wire.
6.Brown–Transmitnegative(-)wire.
TheNMEAwiresontheproduct’spower/datacableshould
beconnectedtoacompatibleNMEA0183devicesasshown
inthetablebelow:
Ray260NMEA0183device
Yellow–Receivepositive(+)
to
Transmitpositive(+)
Green–Receivenegative(-)
to
Transmitnegative(-)
White–Transmitpositive(+)
to
Receivepositive(+)
Brown–Transmitnegative(-)
to
Receivenegative(-)
ConnectingNMEA0183wires
NMEA0183wiresshouldbeconnectedsecurelyandcoveredto
preventcorrosion.
4.5Loudhailerconnection
Asingle30wattloudhailercanbeconnectedtothebasestation
viatheloudhailerwiresonthepower/datacable.
2
1
D12813-1
1
(+)Hailerwire(Purple)
2
(-)Hailerwire(Gray)
Connectingloudhailerwires
Loudhailerwiresshouldbeconnectedsecurelyandcoveredto
preventcorrosion.
22
Ray260
