4.6Handsetconnection
Upto3stationscanbeconnectedtotheunit.
Astationmustincludeahandsetandcanincludeapassiveor
anactivespeaker.Ahandsetmustbeconnectedtothestation
1port(HS1),thishandsethaspriorityoverotherconnected
handsets.
Optionalextensionandadaptorcablescanbeusedtoincrease
thedistanceofthehandsetfromthebasestation,ortoadda
passivespeaker.Themaximumextendedcablelengthfrom
basestationtohandsetis50metres(164ft).
Note:Youcannotconnectanactiveandapassivespeakerto
thesamestation.
Referto4.7Passivespeakerconnectionand4.8Activespeaker
connectionfordetailsonconnectingthehandsetandspeakers.
Connectinghandsetsandcables
Followthestepsbelowtoconnecthandsetsandextension
cablestogether.
1.Ensurethecableconnectorsarecorrectlyorientated.
2.Ensureconnectorsarefullyinserted.
3.TightenlockingcollarsbyRotatingclockwise.
4.7Passivespeakerconnection
Apassivespeakercanbeconnectedtothehandsetcableusing
theexternalspeakerpigtailwires.
0
D12614-3
1
4
3
2
5
1.Basestation
2.Handset
3.Handsetextensioncable(optional)
4.Handsetadaptorcable
5.Passivespeaker
Note:Whenusingtheoptionalhandsetextensioncablethe
extensioncablemustbeconnectedtothebasestationsideof
thespeaker.
Cablesandconnections23
