54 SportPilot and SportPilot Plus - Owner’s Handbook
5 Compass Calibration
5.2 Heading alignment without linearizing
If required, you can align the heading to magnetic North without
carrying out compass linearization:
1. With the SportPilot in Standby mode, press and hold the end of the
control stalk (
NAV) for 10 seconds – the red AUTO and yellow
NAV lights will begin to flash alternately.
2. Steer your boat so that it is pointing to magnetic North,
(determined using a compass, GPS or a land reference).
3. Momentarily press either the
-1 or +1 degree course change keys
(located on the top of the control stalk).
To exit and save changes
To save any changes and exit heading alignment, momentarily press
in the end of the control stalk (
NAV).
To exit without saving changes
If you wish to exit without saving any changes, turn the control stalk
to the first pilot position (
LO) and then back to STANDBY.
D1403-2
