Renishaw ATOM User Manual

56
ATOM linear encoder system
Output signals
Pin 1 Pin 10
ACi JST output connector
Pin 1
Pin 16
ACi FPC input connector
Input signals
1
All power connections should be used either to minimise voltage drop down the cable or incorporate voltage sensing.
Function Signal Pin
Power
1
5 V 7, 8
0 V 3, 6, 11, 14
Incremental
V
1
+ 12
− 13
V
2
+ 15
− 16
Reference mark
V
0
+ 4
− 5
Set-up V
X
1
Remote CAL CAL 2
Do not connect - 9, 10
Pin
Function Signal JST connector
A-9412-1001 cable
(15-way D-type)
Power 5 V 9 7, 8
0 V 10 2, 9
Incremental
A
+ 1 14
− 2 6
B
+ 3 13
− 4 5
Reference mark
Z
+ 5 12
− 6 4
Set-up X 7 1
Remote CAL CAL 8 11
