Ricoh IM 350 User Manual

4. Turn on the main power switch of the machine.
3
2
1
DRS703
1. Indicator (orange)
When 100BASE-TX is operating, the LED is lit orange.
2. Indicator (green)
When 10BASE-T is operating, the LED is lit green.
3. Indicators (both orange and green)
When 1000BASE-T is operating, both LEDs are lit.
• When Energy Saver mode is enabled, the LEDs may not light up.
Obtaining an IP address automatically (IPv4 DHCP)
The machine is set to obtain IP addresses automatically as a factory default.
1. Press [Home] ( ) at the bottom of the screen in the center.
2. Flick the screen to the left, and then press the [User Tools] icon ( ).
3. Press [Machine Features].
4. Press [System Settings].
5. Press [Interface Settings] tab.
6. Press [Network].
7. Press [Machine IPv4 Address].
Connecting and Setting the Network
19

Ricoh IM 350 Specifications

General

Print Resolution	1200 x 1200 dpi
Maximum Paper Size	A4
Duplex Printing	Yes
Scan Resolution	600 x 600 dpi
Memory	2 GB
Paper Output Capacity	250 sheets
Supported Paper Sizes	A4, A5, A6, B5, B6
Mobile Printing Support	Yes
Copy Resolution	600 x 600 dpi
Fax	Optional
Power Source	220 - 240 V, 50/60 Hz
Print Speed	35 ppm
Connectivity	USB, Ethernet
Warm-up Time	24 seconds
Hard Disk Drive	Optional 320 GB
Supported Paper Weight	60-220 g/m²
Copy Speed	35 cpm
Functions	Print, Copy, Scan
Fax Speed	33.6 kbps
Network Connectivity	Ethernet
