4. Specify the IP address, Subnet Mask, and Default Gateway.
When DHCP is enabled, the IP address can be obtained automatically from a network device with
the DHCP server function.
5. Configure the other settings as necessary, and then click [Submit].
6. Exit the web browser.
7. Disconnect the Ethernet interface cable from the computer used for setup, and then
connect the cable to a network device, such as a hub.
8. Set the IP address of the USB device server in the printer driver used for printing.
• The USB device server does not support "Quick Install" and installation using the
SmartDeviceMonitor for Client port. A port must be set independently when a printer driver is
installed.
• To print using Port 9100 or LPR, see Driver Installation Guide and make the following settings:
1. Specify the IP address for the USB device server using the "Add Standard TCP/IP Printer Port
Wizard".
2. Select "Custom" for the device type.
3. For Port 9100, select "Raw" as the protocol, and then specify "9100" for the port number. For
LPR, select "LPR" as the protocol, and then specify "lp" as the queue name.
• For IPP printing, see "Using the IPP port", Driver Installation Guide. To specify the URL of the
machine during the procedure for adding printers, enter "http://(IP address of the USB device
server) /ipp/lp".
1. Getting Started
56

Ricoh IM 350 Specifications

General

Print Resolution	1200 x 1200 dpi
Maximum Paper Size	A4
Duplex Printing	Yes
Scan Resolution	600 x 600 dpi
Memory	2 GB
Paper Output Capacity	250 sheets
Supported Paper Sizes	A4, A5, A6, B5, B6
Mobile Printing Support	Yes
Copy Resolution	600 x 600 dpi
Fax	Optional
Power Source	220 - 240 V, 50/60 Hz
Print Speed	35 ppm
Connectivity	USB, Ethernet
Warm-up Time	24 seconds
Hard Disk Drive	Optional 320 GB
Supported Paper Weight	60-220 g/m²
Copy Speed	35 cpm
Functions	Print, Copy, Scan
Fax Speed	33.6 kbps
Network Connectivity	Ethernet
