4. Click the [Ports] tab, and then click [Configure Port].
The [Port Configuration:] window appears.
Windows 7, Windows Server 2008 R2:
1. On the [Start] menu, click [Devices and Printers].
2. Right-click the icon of the machine you want to use, and then click [Printer Properties].
3. Click the [Ports] tab, and then click [Configure Port].
The [Port Configuration:] window appears.
Using Windows Print Server as a Network Printer
Describes the driver installation procedure for Windows print server.
1. Quit all applications. (Do not close this manual.)
2. Insert the provided CD-ROM into the computer's CD-ROM drive.
If the [AutoPlay] dialog box appears, click [Run AUTORUN.EXE].
3. Select an interface language, and then click [OK].
4. Click [PostScript 3 Printer Driver].
5. The software license agreement appears in the [License Agreement] dialog box. After
reading the agreement, click [I accept the agreement.], and then click [Next].
6. Select the check box of the machine model you want to use.
7. Double-click the machine name to display the machine settings.
8. Click [Port :], and then click [Add] in the [Change settings for 'Port'] box.
9. Click [Network Printer], and then click [OK].
10. Double-click the computer name you want to use as a print server in the [Browse for
Printer] window.
11. Select the machine you want to use, and then click [OK].
12. Check that the port of the selected printer is displayed in [Port :].
13. Configure the user code, default printer, and shared printer as necessary.
14. Click [Continue].
The installation starts.
15. Click [Finish].
Select one of the options to restart the computer either now or later, and then click [Finish].
4. Print
68
