Ricoh pentax KP User Manual

1
Introduction
19
When shooting with the viewfinder, information appears in the
viewfinder.
t Memo
• The information is displayed in the viewfinder when 0
is pressed halfway, or during the meter operating time
(default setting: 10 sec.). You can change the meter
operating time in [3 Meter Operating Time] of the E1 menu.
(p.34)
• The AF point in use for autofocus appears in red
(Superimpose AF Area) when 0 is pressed halfway.
You can turn this function off in [Superimpose AF Area] of
[Viewfinder Overlay] in the A5 menu. (p.26)
• You can adjust the viewfinder
image sharpness using the diopter
adjustment lever. If it is difficult to
move the diopter adjustment lever,
lift up and remove the eyecup.
Adjust the diopter setting until the
AF frame in the viewfinder looks
sharp and clear.
Viewfinder
1 AF frame (p.45) 11 Sensitivity (p.54)/
Exposure compensation
value/Image storage
capacity/Wireless mode
channel (p.120)/AF
Active Area (p.60)
2 Spot metering frame
(p.57)
3 AF point (p.60)
4 Flash indicator (p.57)
5 Focus Method (p.59)
6 Shutter speed/AF Mode
(p.60)/Exposure time for
timed exposure in M
mode/Number of shots
for Bracketing
S Auto (27 AF
Points)
M Zone Select
N Select
O Expanded Area
AF (S)
7 Aperture value/Bracket
value for Bracketing
P Expanded Area
AF (M)8 Focus indicator (p.45)
9 EV bar scale/Electronic
Level (p.20)
Q Expanded Area
AF (L)
10 ISO/ISO AUTO R Spot
12 AE Lock
13 Change AF Area (p.60)
1
4
19
181716151413
61011
12
2
1
3
5 7 8 9
14 Multi-exposure (p.69) 18 EV Compensation
(p.56)/Bracketing (p.66)
15 AE Metering (p.57)
16 Shake Reduction 19 File Format (p.48)
17 Flash Exposure
Compensation (p.57)
