11 Display Control RIGOL
DS6000 User’s Guide 11-5
To set the Waveform Brightness
When you press DISP  WaveIntensity or when the menu is hidden, you can
turn to adjust the waveform brightness of the analog channel. The default is
50% and the range available is from 0% to 100%.
To Set the Screen Grid
Press DISP  Grid to set the screen grid type.
 : turn the background grid and coordinate on.

: turn the background grid off and turn the coordinate on.

: turn the background grid and coordinate off.
To Set the Grid Brightness
Press DISP  Brightness to set the brightness of the screen grid. Turn to
adjust the grid brightness. The default is 50% and the range available is from 0% to
100%.
To Set the Menu Display
Press DISP  MenuDisplay to set the menu display time. The menu will hold for a
specified period of time after the last button-pressing action and then hide. The
display time can be set to 1 s, 2 s, 5 s, 10 s, 20 s or Infinite (the menu does not hide).
