7.13.5 LCP DX supervisory table
Tab. 14: LCP DX supervisory table – analogue variables
BMS Ad-
dress
Description UOM Min Max Read/
Write
Note
1 Reserved – (not used or other special appli-
cation or internal debug)
°C -99.9 99.9 R Only for Service/
Manufacturer
2 B2 probe value: LCP Server IN °C -99.9 99.9 R Customer
3 B3 probe value: LCP Server IN °C -99.9 99.9 R Customer
4 B4 probe value: LCP Server IN °C -99.9 99.9 R Customer
5 Reserved – (not used or other special appli-
cation or internal debug)
°C -99.9 99.9 R Only for Service/
Manufacturer
6 B6 probe value: ROOM Server OUT °C -99.9 99.9 R Customer
7 B7 probe value: ROOM Server OUT °C -99.9 99.9 R Customer
8 B8 probe value: ROOM Server OUT °C -99.9 99.9 R Customer
9 B9 Probe value: Compressor discharge
temperature
°C -99.9 99.9 R Customer
10 B10 Probe value: Compressor suction tem-
perature
°C -99.9 99.9 R Customer
11 B11 probe value: High pressure – Compres-
sor Discharge Pressure
bar -99.9 99.9 R Customer
12 B12 probe value: Low pressure – Compres-
sor Suction Pressure
bar -99.9 99.9 R Customer
13 Evaporator temperature from Low pressure
conversion
°C -99.9 99.9 R Customer
14 Condensing temperature from High pres-
sure conversion
°C -99.9 99.9 R Customer
15…20 Reserved – (not used or other special appli-
cation or internal debug)
––––Only for Service/
Manufacturer
21 Server Medium Temp Out – (Room) °C -99.9 99.9 R Customer
22 Server Medium Temp In – (LCP) °C -99.9 99.9 R Customer
23…44 Reserved – (not used or other special appli-
cation or internal debug)
––––Only for Service/
Manufacturer
45 Compressor Rotor speed rps 0 999.9 R Customer
46 Compressor Motor current A 0 99.9 R Customer
47 Reserved – (not used or other special appli-
cation or internal debug)
rps 0 999.9 R Only for Service/
Manufacturer
48 Main Setpoint LCP °C -99.9 99.9 R/W Customer
49…207 Reserved – (not used or other special appli-
cation or internal debug)
––––Only for Service/
Manufacturer
