11 Technical specifications
11
50 Rittal Liquid Cooling Package
11.5 Total refrigerant charge
11.6 Refrigerant pipes
Connection diameter LCP Rack DX/LCP Inline DX 12 kW: 12 mm/12 mm
System: LCP DX + condenser + winter kit mod-
ule (in case of it)
Fill volume up to a line length
of 5 m [kg]
Fill volume per metre above
5m [kg]
System with standard condenser 2.8 0.03
System with low temperature condenser and winter
kit module
4.8 0.03
System with high temperature condenser 2.65 0.03
Tab. 23: Total refrigerant charge
Type of
condenser
Connection diameter condenser
liquid line/hot gas line
[mm]
Equivalent
length
External diameter of coolant lines
liquid line/hot gas line
[mm]
Standard 22/22 Up to 45 m 12/12
Low temperature 16/16 Up to 45 m 12/12
High temperature 22/22 Up to 45 m 12/12
Tab. 24: Refrigerant pipes
