11 Technical specifications
11
48 Rittal Liquid Cooling Package
11.3 Low temperature unit (3311.361 and 3311.362)
11.3.1 Low temperature condenser for ambient temperatures up to -40°C
11.3.2 Winter kit module for operating the low temperature condenser unit
Technical specifications
Description/Model No. Low temperature condenser / 3311.361
Dimensions and weight
Dimensions width x height x depth [mm] 1582 x 811 x 550
Weight, max. [kg] 44
Electrical connection
Type of electrical connection Connection clamp
Rated voltage [V, Hz] 230/1~/N/PE, 50 230/1~/N/PE, 60
Startup current [A] 2.3 2.1
Pre-fuse T [A] 6 6
Duty cycle [%] 100
Cooling circuit
Coolant/Fill volume [kg] R410A/see tab. 23 "Total refrigerant charge"
Connection diameter refrigerant pipes [mm] See tab. 24 "Refrigerant pipes"
External diameter of coolant lines [mm] See tab. 24 "Refrigerant pipes" (1 mm wall thickness)
Other information
Storage temperatures [°C] -40…+50
Ambient temperature [°C] -40…+45
Noise level [dB(A)]
(Open air above reflective flooring, distance 10 m)
43
Tab. 20: Technical specifications for the low temperature condenser unit
Technical specifications
Description/Model No. Winter kit module / 3311.362
Dimensions and weight
Dimensions width x height x depth [mm] 505 x 400 x 305
Weight, max. [kg] 35
Electrical connection
Type of electrical connection Connection clamp
Rated voltage [V, Hz] 230/1~/N/PE, 50 230/1~/N/PE, 60
Startup current [A] 0.6 0.6
Pre-fuse T [A] 6 6
Duty cycle [%] 100
Tab. 21: Technical specifications for the winter kit module
