Rittal LCP Rack DX 12 User Manual

Rittal Liquid Cooling Package 49
11 Technical specifications
11
11.4 High temperature condenser for ambient temperatures up to +53°C
Cooling circuit
Coolant/Fill volume [kg] R410A/see tab. 23 "Total refrigerant charge"
Connection diameter refrigerant pipes [mm] See tab. 24 "Refrigerant pipes"
External diameter of coolant lines [mm] See tab. 24 "Refrigerant pipes" (1 mm wall thickness)
Other information
Storage temperatures [°C] -40…+50
Ambient temperature [°C] -40…+45
Technical specifications
Description/Model No. High temperature condenser / 3311.363
Dimensions and weight
Dimensions width x height x depth [mm] 2282 x 818 x 552
Weight, max. [kg] 68
Electrical connection
Type of electrical connection Connection clamp
Rated voltage [V, Hz] 230/1~/N/PE, 50 230/1~/N/PE, 60
Startup current [A] 3 2.8
Pre-fuse T [A] 6 6
Duty cycle [%] 100
Cooling circuit
Coolant/Fill volume [kg] R410A/see tab. 23 "Total refrigerant charge"
Connection diameter refrigerant pipes [mm] See tab. 24 "Refrigerant pipes"
External diameter of coolant lines [mm] See tab. 24 "Refrigerant pipes" (1 mm wall thickness)
Other information
Storage temperatures [°C] -20…+55
Ambient temperature [°C] -20…+53
Noise level [dB(A)]
(Open air above reflective flooring, distance 10 m)
45
Tab. 22: Technical specifications for the high temperature condenser unit
Technical specifications
Tab. 21: Technical specifications for the winter kit module
