Rockwell Automation Publication 280E-PM001A-EN-P – August 2011 69
ArmorStart
®
EtherNet/IP
™
Communications & Control Programming Manual Appendix A
Miscellaneous Faults
• For Bulletin 284E units, this fault is actually the logical OR of the drive’s
Auxiliary Input fault (fault code F2), Heatsink Over Temperature (fault
code F8), Params Defaulted fault (fault code F48) and SVC Autotune
fault (fault code F80).
• This fault cannot be disabled.
Bulletin 280E Blink Patterns
Table 3 – Fault LED Indicators for Bulletin 280E
Bit/Blink
Pattern
Auto-
Resettable
Bulletin 280E/281E
Trip Status Description
1 No Short Circuit The circuit breaker (140M) has tripped.
2Drive
Controlled
Overload The load has drawn excessive current and
based on the trip class selected, the device
has tripped.
3Drive
Controlled
Phase Loss The ArmorStart has detected a missing
phase.
4 — Reserved Not Used
5 — Reserved Not Used
6Drive
Controlled
Control Pwr Loss
(Switched Power)
The ArmorStart has detected a loss of the
control power voltage.
7Drive
Controlled
Input Fault This error indicates a shorted sensor, shorted
input device, wiring input mistakes, or a
blown output fuse.
8Drive
Controlled
Over Temperature This fault is generated when the operating
temperature has been exceeded. This fault
cannot be disabled.
9Drive
Controlled
Phase Imbalance The ArmorStart has detected a voltage
imbalance.
10 Drive
Controlled
Control Power (24V DC)
Lost (Unswitched
Power)
The 24V DC power supply is below tolerance
threshold.
11 — Reserved Not Used
12 — Reserved Not Used
13 No EEprom This is a major fault, which renders the
ArmorStart inoperable. Possible causes of
this fault are transients induced during
EEprom storage routines.
14 No Hdw Flt This fault indicates that a serious hardware
problem exists.
15 — Reserved Not Used
16 — Reserved Not Used
