MFX/IFX Parameters
40
00 THRU
01 EQUALIZER
This is a four-band stereo equalizer (low, mid x 2, high).
L in L out
R outR in
Parameter Value Explanation
Low Freq
(Low Frequency)
20, 25, 31, 40, 50,
63, 80, 100, 125,
160, 200, 250, 315,
400 [Hz]
Frequency of the low range
Low Gain -15–+15 [dB]
Amount of boost/cut for the low-
frequency range
Mid1 Freq
(Mid1 Frequency)
200, 250, 315, 400,
500, 630, 800,
1000, 1250, 1600,
2000, 2500, 3150,
4000, 5000, 6300,
8000 [Hz]
Frequency of the middle range 1
Mid1 Gain -15–+15 [dB] Gain of the middle range 1
Mid1 Q 0.5, 1.0, 2.0, 4.0, 8.0
Width of the middle range 1
Set a higher value for Q to narrow the
range to be affected.
Mid2 Freq
(Mid2 Frequency)
200, 250, 315, 400,
500, 630, 800,
1000, 1250, 1600,
2000, 2500, 3150,
4000, 5000, 6300,
8000 [Hz]
Frequency of the middle range 2
Mid2 Gain -15–+15 [dB] Gain of the middle range 2
Mid2 Q 0.5, 1.0, 2.0, 4.0, 8.0
Width of the middle range 2
Set a higher value for Q to narrow the
range to be affected.
HighFreq
(High Frequency)
2000, 2500, 3150,
4000, 5000, 6300,
8000, 10000,
12500, 16000 [Hz]
Frequency of the high range
High Gain -15–+15 [dB]
Amount of boost/cut for the high-
frequency range
Level 0–127 Output Level
02 SPECTRUM
This is a stereo spectrum. Spectrum is a type of filter which modifies
the timbre by boosting or cutting the level at specific frequencies.
L in L out
R outR in
Parameter Value Explanation
Band1
(Band1 (250 Hz))
-15–+15 [dB] Gain of each frequency band
Band2
(Band2 (500 Hz))
Band3
(Band3 (1000 Hz))
Band4
(Band4 (1250 Hz))
Band5
(Band5 (2000 Hz))
Band6
(Band6 (3150 Hz))
Band7
(Band7 (4000 Hz))
Band8
(Band8 (8000 Hz))
Q 0.5, 1.0, 2.0, 4.0, 8.0
Simultaneously adjusts the width of the
adjusted ranges for all the frequency
bands.
Level 0–127 Output Level
