AdEM™-PTZ
ROMET LTD. 15
UNC FLOW LOW LIMIT
ATMOSPHERE PRESSURE
PEAK UNC FLOW reset
MAX GAS PRESSURE reset
MIN GAS PRESSURE reset
MAX GAS TEMP reset
MIN GAS TEMP reset
MAX CASE TEMP reset
MIN CASE TEMP reset
INTERVAL SETTINGS 5 Minute to 24-hour interval period
INTERVAL TYPE Full fields, fixed 4 fields and selectable fields.
INTERVAL FIELD
CUSTOM DISPLAY
DATE AND TIME
SITE LOCATION
CUSTOMER ID
✓ D versions prior to D05 are not approved to use in Canada for legal metrology purpose.
✓ From Software, for firmware versions D05 and higher, some of the parameters are protected by Event
Logger, Password and Hardware Switch. Other metrologically significant parameters are protected by Event
Logger Type A and Password, therefore they are available for change when Hardware Switch is set in Disable
position. These parameters can be configured by RometLink software only. Refer to Measurement Canada
document S-EG-06 for Event Logger Type A (self-contained Event logger) information.
✓ See Table 1 – Romet products Standard Setup Parameters for parameters monitored by Event Logger
overall and protected by Event Logger type A.
How to ENABLE/DISABLE Program Switch
To gain full access to Setup Mode or Calibration Mode, Program Switch Jumper must be located on “En” position.
Following is the procedure how to En/Dis Program Switch.
Fig.11 Location of Program Switch
(Jumpers) – overview
Fig.12 Location of Program Switch (Jumpers) –
close-up view
Right side connection: Enable (En)
Left side connection: Disable (Dis)
