AdEM®-PTZ
ROMET LTD. 77
AdEM®-PTZ ALLOWABLE RANGE OF APPLICATION FOR SOME PARAMETERS
Allowable Base Pressure and Avg. Atmospheric Typical Base Pressure Typical Avg. Atmospheric
Imperial = 10.00 Psia to 16.00 Psia 14.73 Psia 14.73 Psia
Metric = 0.70000 bar to 1.10000 bar 1.01325 bar 1.01325 bar
Metric = 70.000 kPa to 110.000 kPa 101.325 kPa 101.325 kPa
Allowable Base Temperature Typical Base Temperature
Imperial = 32°F to 122°F Imperial = 60°F
Metric = 0°C to 50°C Metric = 0°C, 15°C, 20°C
Allowable NX19 Composition of Gas
Gravity = 0.550 to 0.900
CO2 = 0.00% to 15.00%
N2 = 0.00% to 15.00%
Allowable SGERG88 Composition of Gas
Gravity = 0.550 to 0.900
Hs = 15.00 to 48.00 MJ/CM
(400.00 to 1300.00 BTU/CF)
CO2 = 0.00% to 30.00%
H2 = 0.00% to 10.00%
Allowable AGA8-D2 Range of Application AGA-G1 AGA-G2
Methane 50.00-100.00 Gravity = 0.550 to 0.900 Gravity = 0.550 to 0.900
Nitrogen 0.00-50.00 CO2 = 0.00% to 30.00% CO2 = 0.00% to 30.00%
Carbon Dioxide 0.00-30.00 Hs = 15.00 to 48.00MJ/CM N2 = 0.00% to 50.00%
Ethane 0.00-20.00 (400.00 to 1300.00 BTU/CF)
Propane 0.00-10.00
Water 0.00-0.05
Hydrogen Sulphide 0.00-0.05
Hydrogen 0.00-10.00
Carbon Monoxide 0.00-3.00
Oxygen 0.00-0.05
iso-Butane 0.00-3.00
n-Butane 0.00-3.00
iso-Pentane 0.00-1.00
n-Pentane 0.00-1.00
n-Hexane 0.00-0.20
n-Heptane 0.00-0.20
n-Octane 0.00-0.05
n-Nonane 0.00-0.05
n-Decane 0.00-0.05
Helium 0.00-0.50
Argon 0.00-0.50
Allowable index and output pulses for AdEM®-PTZ
Imperial (cf) Metric (m³)
Index: 0.01, 1, 10, 100, 1000, 10000 Index: 0.0001, 0.01, 0.10, 1.00, 10.00, 100.00
Output: 1, 10, 100, 1000, 10000 Output: 0.01, 0.10, 1.00, 10.00, 100.00
Note: Output cannot be less than Input.
