AdEM™-PTZ
ROMET LTD. 40
Testing Output Pulse using Pushbutton
The Output Pulse test menu provides an effective method for verifying the output pulses circuitry and their
connection device. The AdEM®-PTZ have 3 channels of output pulse. When doing the test, the pulses will be
generated from channel 1, 2, 3 step by step. Each channel will generate 3, 4, 5 pulses respectively. The pulse width
and space are based on the respective setting of the AdEM®-PTZ.
This function is very useful when AdEM®-PTZ is connected with ERT or other AMR devices. It can test whether the
entire system as well as the connections are working properly. This function is protected by hardware Program
Switch. It can be factory disabled.
To test output pulse, the following procedure needs to be performed:
▪ Press and hold pushbutton for about 8 seconds until LCD shows “OUTPUT”
▪ Upon “OUTPUT” release pushbutton promptly
▪ Pulses are automatically generated
