2 TECHNICAL SPECIFICATIONS OF THE MACHINERY
USER'S AND
MAINTENANCE
MANUAL
Date: 01/31/2020
Code MAN D185T4F-DB
ENG
Air Compressor: D185T4F-DB
Revision 03
The general technical specifications of the machinery are reported below
2.1 General technical specifications
2.2 Technical specifications of the compressor
D185T4F
DESCRIPTION TECHNICAL VALUES AND DATA
Service pressure 8.2 bars, 120 psi
Min. pressure 5 bars, 73 psi
Max. pressure 9.7 bars, 140 psi
Rated payload at service pressure
5200 lt/min, 185 CFM
Cooling system Hydraulic oil (*)
Hydraulic system capacity 9 lt, 2.4 gal
Separator tank capacity 20 lt, 5.3 gal
(*) We recommend ROTAIR COMPRESSOR 46
Copyright © 2014, ROTAIR S.P.A. - All rights reserved. This manual is intellectual property of ROTAIR S.P.A.
Its full or partial reproduction is forbidden under any form, on any support and by any means, without the written
authorization by ROTAIR S.P.A.
Page
11/66
D185T4F-DB
DESCRIPTION TECHNICAL VALUES AND DATA
Length (Body) 1835 mm – 72.2 inches
Width 1030 mm – 40.5 inches
Height (with hood closed) 1530 mm – 60.2 inches
Mass 793 kg – 1748 lbs
Compression system Screw single-stage
Fuel tank capacity 90 lt – 23.75 gal
D185T4F-DB
